- Size: 20.4*33.4*1
- Place of Origin: Guangdong Shenzhen
- Brand Name: Zhiang
- Model Number: ZAZ-040
- Weight: 0.005 kg
Technical indicators:
Technical index name: Numerical
Fingerprint sensor principle: RF fingerprint sensor
Detection of dermal capacity: detection dermal ability
Fingerprint capacity: 162 (to 930)
False accept rate (FAR): 0.008% (safety grade 3)
FRR (FRR): 0.005% (safety grade 3)
The average speed of matching: 1
Matching mode:
Alignment: (1:1)
Search mode: (1:N)
Profile: 256 bytes
Template file: 512 bytes
Security level: level five (from low to high: 1,2,3,4,5)
Antistatic ability: 15KV
Abrasion resistance of high strength: 1 millions of times
Work environment:
Temperature: -20 ℃ - 65 ℃
Relative humidity: 40%RH - 85%RH (no treatment)
The storage environment:
Temperature: -40 ℃ - 85 ℃
Relative humidity: <85%H (no treatment)
Computer interface: UART (TTL logic level) or USB1.1
The communication baud rate (UART): (9600*N) BPS and N=1~12 (the default value of N=6, namely 57600bps)
Power supply voltage: 5V
Supply current:
Working current: 100mA (typ)
The peak current: 150mA
Dimensions (L*W*H):
Fingerprint sensor: 20.3 * 16.7 (mm)
Fingerprint acquisition area: 9.85 * 0.91 (mm)
Fingerprint module size: 30 x 22 (mm)
- Size: 20.4*33.4*1
- Place of Origin: Guangdong Shenzhen
- Brand Name: Zhiang
- Model Number: ZAZ-040
- Weight: 0.005 kg
