Product Details
- Size: 110*48*34.03mm
- Place of Origin: Guangdong Shenzhen
- Brand Name: Zhiang
- Model Number: LD-9900
- Weight: 0.005 kg
The performance index:
The power supply voltage: 5 v
Working current: 100 ma (typical)
Peak current: 150 ma
Fingerprint image input time: < 0.5 seconds
Window size: 14 x 18 mm
Validation: support fingerprint verification (1:1) and fingerprint search (1: N)
Profile: 256 bytes
Template file: 512 bytes
Storage capacity: 1000
Security rating: 5 (from low to high: 1, 2, 3, 4, 5)
Recognize false rate (FAR) : 0.001% or less (security level 3)
Rejected boomed (FAR) : 0.0001% or less (security level 3)
Search time: < 1.0 seconds (the latter, the average)
Working environment:
Temperature: - 40 ° C to + 70 ° C
Relative humidity: 40% RH to 40% RH (no lon)
Communication interface: RS - 232 standard interface/USB interface
Fingerprints size: 110 x 48 x 34.03 mm
Development platform, support for Windows, Windows CE, Linux, and B/S, C/S architecture platform, such as more convenient application and development on the system integrators.
Optical blu-ray, mouse type of fingerprints.
The power supply voltage: 5 v
Working current: 100 ma (typical)
Peak current: 150 ma
Fingerprint image input time: < 0.5 seconds
Window size: 14 x 18 mm
Validation: support fingerprint verification (1:1) and fingerprint search (1: N)
Profile: 256 bytes
Template file: 512 bytes
Storage capacity: 1000
Security rating: 5 (from low to high: 1, 2, 3, 4, 5)
Recognize false rate (FAR) : 0.001% or less (security level 3)
Rejected boomed (FAR) : 0.0001% or less (security level 3)
Search time: < 1.0 seconds (the latter, the average)
Working environment:
Temperature: - 40 ° C to + 70 ° C
Relative humidity: 40% RH to 40% RH (no lon)
Communication interface: RS - 232 standard interface/USB interface
Fingerprints size: 110 x 48 x 34.03 mm
Development platform, support for Windows, Windows CE, Linux, and B/S, C/S architecture platform, such as more convenient application and development on the system integrators.
Optical blu-ray, mouse type of fingerprints.
