- Size: L*W*H
- Place of Origin: Guangdong Shenzhen
- Brand Name: Zhiang
- Model Number: ZWY-060-C
- Weight: 0.050 kg
The performance index:
Supply voltage: 4.2-7.5V
Supply current:
Working current: 100mA (typ)
The peak current: 120mA
The time of fingerprint image input: <0.5 seconds
Matching mode:
Comparison (1:1)
Search method (1:N)
Profile: 256 bytes
Template file: 512 bytes
Storage capacity: 1000
Security level: level five (from low to high: 1, 2, 3, 4, 5)
False accept rate (FAR): <0.005% (safety grade 3)
FRR (FRR): <0.008% (safety grade 3)
The search time: <1.0 seconds (1:1000, mean)
Computer interface: UART (TTL logic level) or USB2.0
The communication baud rate (UART): (9600 x N) BPS and N=1~12 (the default value of N=6, namely 57600bps)
The pixel density: 500dpi
Work environment:
Temperature: -30 ℃ -+85 ℃
Relative humidity: <85%H (no treatment)
Dimensions (L * W * H)
Split:
Module size: 2.2*2.5 (CM)
A fingerprint reader module size: 2.0*3.2 (CM)
Effective collecting area: 1.2*1.5 (CM)
